3I 150CC I5 five-cylinder star four-stroke UAV gasoline engine

3I 150CC I5 five-cylinder star four-stroke gasoline engine

Volume: 149.55cc (5 x 29.91cc)

Cylinder diameter: 36mm

Stroke: 29.4mm

Practical speed range: 1000-6500rpm

Output power: 8.2HP/6500rpm

Tensile force: 23kg

Engine weight: 4600g

Weight of igniter: 430g

Igniter power supply: DC7.4V-12.6V   1000mAH

Recommended propellers: 26×16, 28×14, 30×12 (Two blade ) ；23×16, 26×14 (Three blade)

Fuel: 92 # unleaded gasoline+full synthetic 2T lubricating oil

Lubrication ratio: gasoline: lubricating oil=35:1

3IPOWER is famous for producing high-quality gasoline engines, and is also the first factory in China to independently develop and produce small multi-cylinder four-stroke gasoline engines. 3I 150CC I5 is a professional four-stroke gasoline engine built by 3IPOWER engineers for RC aircraft and fixed-wing UAVs, with high performance and low fuel consumption, large torque and low noise, compact structure and beautiful appearance.

3I150CC I5 uses CM6 spark plug, standard equipped with 3IPOWER special annular exhaust device, smooth exhaust, low voice, surging power and less vibration.

The rear matched WALBRO carburetor makes engine adjustment simple and convenient; The connecting rod is equipped with needle bearing to better lubricate the pin shaft; Unique separate lubrication circulation system makes engine lubrication more sufficient; Unique double piston rings (one lubricating oil ring and one sealing ring) can better seal and lubricate; The unique supercharging structure increases the adaptability of the engine to the environment; The cylinder liner is made of wear-resistant ductile iron. The roundness tolerance of the inner hole of the cylinder block is within 0.01mm, and the accuracy is much higher than 0.03mm of the inner hole roundness tolerance of the aluminum alloy chrome-plated cylinder liner. In principle, the aluminum alloy chrome-plated cylinder liner does not meet the environmental protection requirements of the European Union.

3I150CC I5 product features

*Ultra-high stability, large torque output, ultra-low vibration

*Low fuel consumption, low noise, high wear resistance, power weight ratio greater than 2

*Suitable for long-endurance UAV and RC virtual aircraft

*3IPOWER special annular exhaust device, smooth exhaust and low sound

*The matched Walbro carburetor is reliable in operation and easy to debug

*CNC refined double-needle bearing main connecting rod and solid and durable integral bronze auxiliary connecting rod

*RCEXL automatic angle entry asynchronous ignition system specially manufactured for 3IPOWER

*RCEXL spark plug CM6

*High quality bearing
